FOX 12-30 Hydraulic Crawler Drill is excellent option for drilling rock, can be used in Quarries, Open Pit Mining and Drilling Service Providers. FOX 12-30 generates high productivity with low operating costs.
Advantages:
- Operational Confort
- High Production
- Higher Reach
- Eco Mode
- Low Maintenance Cost
- Operational and Maintenance Simplicity
Top Hammer Hydraulic Crawler Drill with Cabin for Quarries, Mines and Construction
Technical Data | ||
|---|---|---|
Diesel Engine | Traction | |
Manufacturer: Cummins | Maximum speed: 3.8 km/h | |
Model 6cc 6CTA 8.3lt – 234HP | Pulling force: 56.596 N | |
Cooler: Water | Ascent ramp: 36% | |
Diesel Tank Capacity 300 lt | Truck Oscilation: +/- 10º | |
Rod Changer | Compressor Unit | |
Type: Carousel | Type: Screw | |
Capacity: 6+1 rod | Flow: 300 – 347 CFM / PCM | |
Rod greaser: 3.66 m (12’) | Pressure: 105 PSI (7 – 9 bar) | |
Boom | Dust Collector (Standard) | |
Length: 7 meters | Primary collector: Cyclone type / Secondary: 4 filters | |
Length Usable: 4,5 meters | Suction capacity: 35m³/min (882 CFM) | |
Hydraulic Chain Advance | Cleaning System | |
Planetary Reducer System | Cleaning Water (Optional) | |
Water tank capacity: 150 liters (33 gal) | ||
Note: The FOX series of equipment is equipped with a Dust Collector and/or Water Cleaning system to meet the requirements of the Regulatory Norms for Mining NRM, which deals with Decree-Law No. 227 of 02/28/1967. NRM 09 in detail – Items 9.1.3.1 and 9.1.3.2 | ||
Itens Disponíveis | |
|---|---|
Enclosure | Standard |
Safety Sound Kit (Horn and Reverse Alarm) | Standard |
Hydraulic Centralizer | Standard |
Rod Changer | Standard |
Grease Pump | Standard |
Night Lights | Standard |
Digital Boom Inclinometer | Standard |
Hose Tensioner | Standard |
Cabin | Standard |
Interactive Digital Display | Standard |
Electronic Maintenance Alert | Standard |
Anti Jamming | Standard |
Dust Collector (Primary and Secondary) | Opcional |
Air-Conditioned Cabin ROPS/FOPS | Optional |
Emergency Button on Boom | Optional |
Digital Angle Indicator | Optional |
Side and Rearview Mirrors | Optional |
Water Cleaning (Water Tank) | Optional |
Nitrogen Charger | Optional |
Pneumatic Grinder | Optional |
Mechanical Inclinometer for Chassis | Optional |
Depth Meter | Optional |
Lifting Eye | Optional |
Surface Drifter W 19:
Technical Data | |
|---|---|
Working Pressure | 120-140 bar (2.030 PSI) |
Impact Power | 19 Kw (26 hp) |
Impact Frequency | 2.600 bpm |
Weight | 237 kg |
Rotation | 0 – 150 rpm |
Rotation Torque | 750 Nm (533 lbf/ft) |
Thread Type | T38 / T45 |
Hole Size | 2.1/2″ – 4″ |
Rod Length | 3,66m (12”) |
Dimensions:
Transport Dimensions | |
|---|---|
Weight | 13.000kg |
Width | 3.035 mm |
Length | 8.951mm |
Height | 3.752 mm |
